Indoor and outdoor: 500*1000B
Available spacing: P2.6 P2.9 P3.91 P4.81
LED module size 250*250mm
Seamless splicing, perfect installation
Super wide viewing angle, new experience
HD color realistic
High refresh rate and stable display
Low energy consumption and more environmental protection
High-quality module unit board, high brightness, good flatness, strong stability, and more uniform color distribution.
| 1000*500MM PRODUCT PARAMETER | ||||
| pixel pitch | P2.6mm | P2.9mm | P23.91mm | P4.81mm |
| pixel density | 112,896 points/square meter | 65536 points/square meter | 65536 points/square meter | 43264 points/square meter |
| color scheme | 1R1G1B | |||
| LED package | SMD2121 | SMD1921 | ||
| Module size | 250mmx250mm | |||
| drive mode | 1/16 sweep constant current | |||
| Brightness | 1000cd/sqm | 4500cd/sqm | ||
| best viewing distance | 2-30m | 3-40m | 3-40m | 4-50m |
| Cabinet size | 500*500mm/500mmx1000mm | |||
| Cabinet weight | 6.5KG/12KG | 7KG/13KG | ||
| perspective | H: 140°; V: 140° | |||
| refresh rate | 3840HZ | 1920HZ | ||
| grayscale | 16Bits | |||
| power input | AC110V/ 220V ±10%.50HZ | |||
| Average power consumption | 300W/sqm | 250W/sqm | 400W/sqm | |
| Operating temperature | -20℃~+50℃ | |||
| blind spot rate | <1/10000 | |||
| life | >100,000 hours | |||
Curved led screen can be achieved by curved lock, it can make both inner and outer arc0-15 degrees and-15-0 degrees.
